Sensor Type
|
Sony 1/3" CMOS Sensor |
| Scale |
4:3(default)/16:9 Switchable |
| Tv System |
PAL(default)/NTSC Switchable |
|
Resolution
|
1000TVL |
|
Shutter Speed
|
PAL 1/25~1/10000 sec; NTSC 1/30~1/10000 sec |
| Video Output |
CVBS Analog Signal |
| FOV |
FOV-H:125° FOV-D: 155° |
| Shutter Speed |
Auto |
| Minimum Illumination |
0.01Lux |
| White Balance |
Auto |
| DNR |
3DNR 2DNR |
| WDR |
Super WDR |
| Mode |
DAY/CLOUDY/Night/LED |
| Fast Mode Switch |
Long Press Right Button to switch among DAY/CLOUDY/Night/LED |
| Flight OSD |
Voltage/Cam Title/Time/Cross Hair |
| Input Voltage |
4.5V~20V |
| Language |
ENGLISH/ DEUTSCH/ FRANCAIS/ PYCCKNN/ PORTUGUES/ ESPANOL/ 中文 |
| Working Temperature |
-10°~50°C RH90% MAX |
| Working Humidity |
20~80% |
| Storage Temperature |
-20°~70°C |
| Consumption |
50mA±15% @ DC12V 115mA±15% @ DC5V |
| Dimension |
14*14mm; 19*19mm(Add Bracket) |
| Weight |
Plug:4.8g Solder Pad:4.3g(Exclude cable) |
