Foxeer Lollipop V4 FPV Antenna 5.8G High Gain (Set Of 2)

Color:

Red (RHCP)

Black (RHCP)

Connector:

SMA

U.FL

Quantity

Featured Products

RadioMaster Bandit BR3 ExpressLRS 915MHz ELRS TCXO Receiver

RadioMaster TX16S Mark II Max Radio Controller Transmitter

RadioMaster Bandit Nano ExpressLRS 915MHz RF ELRS 1W Module TX

DOGCOM 5200mAh 6S 120C 22.2V LiPo Battery QS8 [DG]

ISDT K2 Air Dual Channel Smart Charger 2-6S AC DC 200w 500w 20A

SUNLU ASA 3D Printer Filament 1.75mm 1KG

Foxeer 5.8G Lollipop 4 High Gain FPV Antenna is here!

Center Frequency	5.7GHz
Gain	2.6dBi
Axial Ratio	Close to 1
Band Width	5.5G~6GHz
Radiation Efficiency	98%
SWR	1.07 at Center Frequency
Polarization	RHCP/LHCP
Case Material	PC+ABS
Weight	SMA/RPSMA: 7.8g
	Straight MMCX: 4.4g
	Angle MMCX: 4.5g
	SMA-10CM: 9.7g
	Angle SMA-15CM: 13.9g
	UFL : 2.8g
	UFL Tube Short: 2.9g
	UFL Tube Long: 3.8g
	Angle MMCX Tube Short: 4.8g
	Angle MMCX Tube Long: 6.8g
Connector & Length	SMA/RPSMA/Straight MMCX/Angle MMCX: Φ11*60mm
	UFL/ UFL Tube Short/ Angle MMCX Tube Short: Φ11*85mm
	SMA-10CM: Φ11*100mm
	SMA 15CM Angle/ UFL Tube Long/ Angle MMCX Tube Long: Φ11*150mm
Quantity	2pcs Antennas
