Foxeer Lollipop V4 FPV Antenna 5.8G High Gain (Set Of 2)

Color:

Red (RHCP)

Black (RHCP)

Connector:

SMA

U.FL

Quantity

Featured Products

TBS Crossfire Micro TX V2 Starter Set

TBS Crossfire Diversity Nano RX

Matek M10Q-5883 GPS COMPASS Module

DOGCOM 5200mAh 6S 120C 22.2V LiPo Battery QS8 [DG]

RadioMaster Bandit BR3 ExpressLRS 915MHz ELRS TCXO Receiver

Infinity 1400mAh 6S 150C 22.2V LiPo Battery XT60 [DG]

Foxeer 5.8G Lollipop 4 High Gain FPV Antenna is here!

Center Frequency	5.7GHz
Gain	2.6dBi
Axial Ratio	Close to 1
Band Width	5.5G~6GHz
Radiation Efficiency	98%
SWR	1.07 at Center Frequency
Polarization	RHCP/LHCP
Case Material	PC+ABS
Weight	SMA/RPSMA: 7.8g
	Straight MMCX: 4.4g
	Angle MMCX: 4.5g
	SMA-10CM: 9.7g
	Angle SMA-15CM: 13.9g
	UFL : 2.8g
	UFL Tube Short: 2.9g
	UFL Tube Long: 3.8g
	Angle MMCX Tube Short: 4.8g
	Angle MMCX Tube Long: 6.8g
Connector & Length	SMA/RPSMA/Straight MMCX/Angle MMCX: Φ11*60mm
	UFL/ UFL Tube Short/ Angle MMCX Tube Short: Φ11*85mm
	SMA-10CM: Φ11*100mm
	SMA 15CM Angle/ UFL Tube Long/ Angle MMCX Tube Long: Φ11*150mm
Quantity	2pcs Antennas
